Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 315

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 315
1252. ORE ROASTINGFURNACE, revolving type.The large cylinder takescharge by the manholes, andrevolves on power-driven rol-lers. The furnace is on atruck to be removed whenrequired. The heated gases pass through the revolving cylinder and to a chimney. MINING. 309
