Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 321

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 321
1265. ADJUSTABLE POST HANGER. 1266. ADJUSTABLE FLOOR STAND,shaft bearing. 1267. CONTINUOUS TRAVERSINGROLLER or ball bearing for an axle. 1268. ROLLER WHEEL ANTI-FRICTIONBEARING. 1269. BALL BEARINGS in an adjustable journal box. A loose sleeve ^ is inserted between 1^^^^ the balls and the shaft /TV… … 1270. Longitudinal section. MILL AND FACTORY APPLIANCES. 315

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
