Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 322

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 322
1270. Longitudinal section. MILL AND FACTORY APPLIANCES. 315 … 1271. ADJUSTABLE HANGER for shafting.A, drop of the hanger. Jointed cap to allow ofremoval of shaft. 1272. SCREW TRAVERSINGBALL BEARING, with balls returningthrough outside passage. Grooves re-cessed in shaft.
