Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 325

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 325
1289. FLEXIBLE LINKCOUPLING.—The end of eachshaft is fitted with a four-armedhub. A series of leather links isinserted between the arms of onehub and those of the other hub,and secured with stud bolts. 1290. Side view. 1291. FLEXIBLE SHAFT COUPLING.—A ball and socketshaft ends with a slot in the… … 1293.
