Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 367

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 367
1510^. MELAN BRIDGE.—A series of arched steelI beams, filled in with Portland cement concrete. Endsof beams resting against thrust plates. … i5iof. STEEL ARCHED CONCRETE BRIDGE, Thatchertype.—The concrete rib of the arch is reinforced by steel barson the inner and outer edge of the concrete rib. CONSTRUCTION AND DEVICES. 361
