Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 408

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 408
MENT WITH TWOLEVERS AND ONE LINK.—Levers A and E are connected by link L to frame /. Lever Ais pivoted to frame J at B andconnected to link L at C. LinkL, connected to lever A at C, uconnected to lever E at D.Lever E, connected to link L atD, is pivoted to frame J at Fand connected to frame / at… … 402 STRAIGHT LINE MOVEMENTS. 1664. OIL SWITCH MOVEMENT WITH TWOLEVERS AND ONE LINK.—Levers A and H are connectedby link E to frame K. Lever A, pivoted to frame K at B, is connected to link E 2X D.Link E, connected to lever Aat D, is connected to lever Hat F. Lever H, connected tolink E at F, is…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
