Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 413

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 413
RAIGHT LINE MOVEMENTS. 1664. OIL SWITCH MOVEMENT WITH TWOLEVERS AND ONE LINK.-Levers A and H are connectedby link E to frame K. Lever A, pivoted to frame K at B, is connected to link E at D.Link E, connected to lever Aat D, is connected to lever Hat F. Lever H, connected tolink E at F, is pivoted… … 1665. OIL SWITCH MOVEMENT WITH THREELEVERS AND THREE LINKS.—Levers A, E, and / areconnected by links G and L to frame O. Lever A, pivoted toframe O at B, is connected to link Q at C. Link Q, con-nected to lever A at C, is con-nected to lever E at D.Lever E, connected to linkQ at D, is pivoted to…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
