Practical mechanical drawing and machine design self taught .. (1907)

Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 86

An illustration from Practical mechanical drawing and machine design self taught .., 1907, leaf 86 — for Pillow Block. Drawthe side and end elevations shown in Fig. 164,and from the side elevation project a plan. Scale—^Half size. MACHINE DRAWING 83 Example 10. Wall Bracket and Bearing. Drawthe side and end elevation partly in section asshown in Fig. 165, and project a complete planbelow.… … ^
