An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 50
132. OBLIQUE SPUR AND BEVEL GEAR. —An oblique tooth spur gear and an obliquebevel gear, operating shafts running at an angularposition. 133. OBLIQUE BEVEL GEAR on shafts atright angles and crossing out of axical plane. 134. GEAR TRAIN—Solutionfor increased speed: Divide themultiple of the number of…
