147. FRICTION MACHINE, for testingfs the friction of wheels at various speeds andloads. The adjustable circular balance holdsthe wheels or vehicle in place. The poundstension on the scale multiplied by the periph-eral velocity in feet per minute gives the foot-pound draft or friction. so… … 148. TORSION DYNAMOME-TER.—To a driving shaft E is attachedat C a helical spring. To the otherend of the spring is attached a trans-mission pulley A and a small pulleyQi, moving freely on the shaft E. AtQ2 another small pulley is fixed to shaft E. The tension of trans-mission displaces the relative…
