Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 63

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 63
171C. BELT SHIPPER.—A taper pinwith a flange at the large end and attachedto a pole. This handy device enables thethrowing of a belt off or on with safety. 56 MEASUREMENT OE POWER. … lyid. THREE HORSEWHIFFLETREES. — Thesecond pair have their centerpins at two-thirds their lengthfrom the inner end and thecenter single tree attached withloose links. 171^. ANEMOMETER formeasuring air currents. A smallwindmill but a few inches in di-ameter geared to a series of dialswhich by known…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
