Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 78

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 78
235. HIGH-SPEED TAN-DEM COMPOUNDENGINE, Harrisburgmodel. 236. TANDEM COMPOUND ENGINE, Phoenix IronWorks model.A direct pipeconnection be-tween the highand low pres-sure cylinder.

Mechanical movements
