Appleton's dictionary of machines, mechanics, engine-work, and engineering (1869)
New York, Appleton · leaf 514
on, Fig. 3094. By means rf these slots the length of the stroke and the position athe tool may be easily and accurately adjusted to suit the work, as will be sufficiently obvious bytion of Fig. 3088. The driving-spindle works in two bearings, one of which, as before mentioned,is cast on the bed of… … The planing of circular surfaces is effected, in this machine, by means of a hollow cylindrical ea-t ironnandrcl L, Figs. 3091 and 3092, accurately turned and titled into the body of the machine, the o ntnbeing exactly under that of the square slide E. This mandrel is provided with a conical 1»…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
