Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 83

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 83
258. JOYS VALVE GEAR for ahorizontal engine. Adjust-ment is made by the angular position of the slottedlink. Valve motion by crankrod and links. 76 STEAM POWER. … 259. BREMME VALVE GEAR withsingle eccentric. The eccentric arm is rockedby the double link connection and is reversedby throwing the link joint over by the handscrew and sector arm, not shown in cut.
