Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 90

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 90
293. RACK GEAR PARALLEL MOTION.— An old pumping device used with a single-acting beam engine. STEAM POWER. 83 … 294. WATT GOVERNOR.—The cen-trifugal action of the balls lifts the sleeve and,through the bell crank, operates the throttlevalve.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
