Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 92

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 92
to take a vertical motion,corresponding to variation in speed, and transmitting it to the valvegear. 304. HORIZONTALCENTRIFUGAL GOV-ERNOR, Bourdon model.The balls are balanced on arigid arm pivoted to the hori-zontal spindle. A sector con the ball arm meshes witha sector pivoted on the hollow… … 86 STEAM POWER.

Mechanical movements
