Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 95

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 95
315. PICKERING GOVERNOR.—The revolving balls are held by springs, the exten-sion of which draws the cap. A, downward andwith it the central valve rod, with direct con-nection to the balanced throttle valve. … 316. PULLEY OR FLYWHEEL GOVER-NOR, Sweets.—The eccentric moves towardthe centre by the centrifugal action of theweight restrained by the spring through theconnecting link. STEAM POWER. 89

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
