Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 265
^ rr:_.if Fig. 224. § 233. reaction to be =%P. AOB is the neutral line ; requiredthe equation of the portion OB referred to 0 as an origin,and to the tangent line through 0 as the axis of X Todo this consider as free the portion mB between any sec-tion m on the right of 0 and the near support, in… … Fig. 225. Fig. 226. ELASTIC CURVES. 253 are the one external force y£Py and the elastic forces act-ing on the exposed surface. The latter consist of Jt theshear, and the tensions and compressions represented inthe figure by their equivalent stress-couple. SelectingN, the neutral axis of ra, as an…
