Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 273
ilevers.—A horizontal beam whose onlysupport consists in one end being built in a wall, as inFig. 229(a), or supported as in Fig.229(&) is sometimes called a canti-lever. Let the student prove that inFig. 229(a) with a single end load P,the deflection of B below the tangentat Ois… … FLEXUBE ELASTIC CURVES. 261 PI2 The greatest deflection of the elastic curve from the rightline joining AB, in Fig. 229(6), is evidently given by theequation for y max. in § 235, by writing, instead of P ofthat equation, the reaction at 0 in Fig. 229(6). This assumesthat the max. deflection occurs…
Mechanics, Applied · Engineering · Strength of materials
