nnecting them with the soilpipe, because a wiped joint cannot be made with cast iron^ Tomake such a connection the end of the lead pipe is ^^wiped ontoa brass thimble, heavy enough to allow it to be joined to the soilpipe by a calked lead joint. The brass thimble is then joined tothe cast-iron pipe… … Fig. 101.—The wash-outcloset. Fig. 102.—The wash-downcloset. water closets are manufactured to conform to special conditions,but those commonly used in the bathrooms of dwellings are ofthree general types. The mechanical construction of each isshown in the following drawings, Figs. 101, 102 and 103…
