yit can be locked to the lead-screw. This is effected by carry-ing the bottom-slideover the bed, to whichit is fitted in the usualway by chipping strips.The parts resting onthe bed are known asthe saddle. A front plate, calledthe apron, is securedto the saddle, andpasses in front of thelead -… … Fig. 175. 190 METAL-WORK the saddle wound back quickly by means of a rack, which isfixed to the bed-plate, and a small pinion, which is fitted tothe apron. Fig. 176 is a section showing the details of clamp nut, apron,and saddle. The transmission of the motion from the mandrilto the lead-screw is…
