end to end, aretwo heavy steel tubes, Band C, 3 in. in diameter, ground perfectly straight, and being true when placed in the cen-ters of a lathe, the object being to get a sti-aight-line motion of the microscope-plate Z>,which slides freely on these true cylinders. Flexure of these cylindrical… … Fig. 6.—Measuring-machine.
