d n1. All the foregoing detailsare duplicated at the opposite and right hand side of the loom. The stud wheel e and stud g rotate clockwise __ , . with uniform velocity. Immediately the stud G Mechanism. J J passes the top centre and commences to descend, it pulls down, assisted by its own gravity,… … tjfi sympathy with the oscillation of shaft s, the lever t and bowl u riseand lift the head 9. The oscillation of the shaft s clockwise is COMPOUND DRIVING OF TWILLING JACQUARDS. 167 further assisted by the spiral spring x acting on the free arm of thelever w. Immediately the stud g passes the…
