Metal-work; a handbook for teachers and students (1914)

Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 337

An illustration from Metal-work; a handbook for teachers and students, 1914, leaf 337
.It must be carefully drawn, and should not take more than 20 to30 minutes. (15.) 4. Small Crank Disc, Pin, and Connecting Bod {Fig. 2).—Themechanism shown in Fig. 2 is used to convert the circular motion 320 METAL-WORK of vertical spindle and crank disc into the reciprocating motion ofthe plate P,… … Fig. 2. WEITTEN EXAMINATION (Three Hours). Instructions. Candidates must attempt Questions 2 and 5 or 6, and notmore than eight questions in all are to be answered. 1. Give a concise definition of each of the following terms,which are chiefly used in correlating a course of metal-work witha science…

Metal-work

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
