Pigs. 2.505 and 2,506.—PI • 2t»ctioo iubUuiuent. Ques. How does it work? Ans. Eddy currents are induced in the two copper pla:shields C, which attract those in the disc, producing in conse-quence a torque in the direction shown by the arrow, against INDICATING DEVICES 1,789 the opposing action of a… … Fig. 2,507.—Diagram showing construction and operation of Hoskins instrument. It is of themodified induction type in which the torque is produced from the direct repulsion betweena primary and a secondary, or induced current. As shown in the diagram, the instrumentembodies the principle of a short…
