The microscope; an introduction to microscopic methods and to histology (1901)
Gage, Simon Henry, 1851-1944 · Ithaca, N.Y. Comstock publishing company · leaf 122
uld have by looking directly into theocular. A. B. The lateral rays from themicroscope and their projection uponthe drawing surface. C. D Rays.from the drawingsurface to ths eye. A. D. A D. Overlapping portions of the two fields, where both the micro-scopic image and the drawing surface, pencil,… … Fig. 97. Put a Wollaston camera lucida (Fig. 97 and Ch. V) in position,and turn the ocular around if necessary so that the broad flat surfacemay face directly upward, as shown in Fig. 97. Elevate the micro-scope by putting a block under the base, so that the perpendicular dis-tance from the upper…
Microscopy
