the pupil of the eye. Axis, Axis. Axial rays Jrom themicroscope and from the draiving sur-face {Ch. V). Camera Lucida. A section of thequadrangular prism showing thecourse of the rays in the pt ism fromthe microscope to the eye. As the raysare tzvice reflected, they have the samerelation on… … Fig. 92. A D, A D. Overlapping portion of the two fields, where both the microscopicimage and the drawing surface, pencil, etc., may be seen. It is represented by theshaded part in the overlapping circles at the right. Ocular. The ocular of the microscope. P. The drawing pencil. Its point is shown…
