The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 94
Fig. 27. … increases from the full to the mid gear, and the rapidity ofthis increase, for a given link, depends directly upon thelength of the rods ; hence with a given mid gear lead open- 80 CONNECTION OF ECCENTKIC EODS. ing that for the full gear will Ibe determined mainly by thislength. Excepting the case…
Steam-engines
