Rankine, William John Macquorn, 1820-1872, Millar, William J, Tait, Peter Guthrie, 1831-1901 · London, C. Griffin and company · leaf 505
lete the preparation ofthe low-pressure diagram draw, ineach case, a series of lines across itparallel to the base 0 B, such asthe dotted lines in each Fig., ofwhich one is marked h i e. Let c denote the ratio 0 B -4- 0 P. Then,in the case of an engine without a reservoir (Fig. 1) draw P£… … THE WORKING OF STEAM IN COMPOUND ENGINES. 457 the points, such as q, thus found, will be the required boundary of theenlarged low-pressure diagram, kqejksJc, which, being joined on to the C D T R Sfl V A TH Ssft A A* R I G » Lb Fig. 4. high-pressure diagram C D K H, makes the combined diagram.…
