Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 270

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 270 — ^ boiler and engine. To begin with, make full-size drawings of the boat;its plan and cross section. Make two wooden molds, onefor the cross section about one-third of the distance from 266 … 268 Model Engineering bow, and another about, or, better still, a trifle behindcenter. The bow piece and stern piece should next bemade of good clean pieces of oak, free from knots. After

Machinery

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
