Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)
Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 373
ent clearly, as well as the method of mountingthe motors in the cradle and clamping them down. The tank is now ready to be covered with galvanizediron. Two pieces are first cut to cover the sides. Theseare drilled full of small holes arranged systematically. 370 Model Engineering Small rivets are… … Fig. 298—Wiring diagram of the motors and controlling rheostats be daubed A^dth various colored paints to representcamouflage. Being that the driving motors of the tank obtain theirpower from the lighting circuit, it will be necessary tohave the tank pull its feed cables \\dth it. An arrange-ment…
