Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 63

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 63 — rig. 34—General arrangement of the lathe and motor within the cabinet In doing this, the grinding disc is set in motion at ahigh speed and the beeswax is pressed to the surface.The heat of friction will cause the beeswax to melt and athin film of it will be deposited upon the polished sur- B/=ILL… … Fig. 35—Side view of the lathe cabinet Lathes and Lathe Work 61 face of the disc. After this film is deposited, a disc ofabrasive paper is then held tightly against the surfacewhile it is revolving. For the model engineer who lives in a small flat, withlittle available space for a workshop, the…

Machinery

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
