Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 343

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 343
commence to turn and at the same instant, the carriage begins itsoutward run and the yarn, being delivered by the rolls, is kept undera slight tension and is twisted; when the carriage reaches the end of COTTON SPINNING its outward run, or stretch, which is about sixty-four inches, it isstopped and… … Fig. 323. Plan of Gearing of the Mule. B, is out of gear as is also the drawing-up friction, T^ The backing-off friction is revolving, as it is driven from a gear on the hub of theloose pulley, which revolves all the time, as the driving belt is slightlywider than the face of the tight pulley and a…
