draw a line to C, and complete the parallellines as in the previous diagram. A C will then be divided into twelve partsfor the inches, add as many 2-in. divisions along the line A B as you requirefeet, with numbers as shown, and the scale is complete. The inches must benumbered from right to left,… … 1. A Trammel. This can also be applied in many ways to bench work. Suppose a friezeor gallery has to be divided intc a given number of parts ; instead of wasting timewith compass or rule, reduce the rail to a convenient scale, treat it as a line A Band divide it as described above. Or again, when a…
