Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 109

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 109
Waste iStock ■ Fig. 172. Stock Prepared for Band-SawingSegments … Woocf Face-Plate - Fig. 173. Partially Assembled Rim and Pattern at the same time with two 1-inch finish nails. The heads ofthese nails should be driven below the surface of the stock. Besure that the segments are concentric w^ith the center of thefaceplate. PATTERN MAKING 93 As soon as the glue is…
