Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)
Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 315
from the small illustration given. To Obtain the True Shape of a Flute and space to which zinc templatesare made, find the true length in the stretch out line of A B, and place it at theside of the diagram, see a b and a b ; transfer the divisions also, and drawshort horizontal lines ; number these… … Diagrams illustrating Development forVeneers on Vase Shape. PRACTICAL SETTING OUT AND APPLIED GEOMETRY. 243
Cabinetwork · Furniture
