Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)

Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 354

An illustration from Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction;, 1910, leaf 354
2. Method of Fixing Rule Joint Stay. CONSTRUCTIONAL BRASSWORK, MOVEMENTS, AND FITTINGS. 265 / / … / / I. Method of Supporting Heavy Flaps. and if set out again half way asat B, the length of the lower slotis obtained, whilst A gives thelower end of the upper slot andB the top end. A small platefixes the centre pivot, and afilling-in end will be necessaryto cover the bar. A tongue onthe fall is…

Cabinetwork · Furniture
