o that a circle or semicircle can be easily divided up into twelve or six equal parts, as in f. 1, p. 25. This would be handy in setting out tops for veneering. As the angle A B C is 90 degs., or a right angle, D would be a line at 60 degs., and C one at 30 degs. A mitre, or line at 45 degs.,… … Method of Dividing FlutedPilasters in Equal Pro-portions. DRAWING—GEOMETRY—PERSPECTIVE, ETC. 27 more arcs from A and C, cutting each other in D. Through D draw a line intothe corner at B, which will be the mitre line. The half mitre is obtained bybisecting the lower portion. Again, a line at 60…
