Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)
Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 51
h draw a line to C, and complete the parallellines as in the previous diagram. AC will then be divided into twelve partsfor the inches, add as many 2 in. divisions along the line A B as you requirefeet, with numbers as shown, and the scale is complete. The inches must benumbered from right to left,… … 1. A Trammel. This can also be applied in many ways to bench work. Suppose a friezeor gallery has to be divided into a given number of parts; instead of wasting timewith compass or rule, reduce the rail to a convenient scale, treat it as a line A B,and divide it as described above. Or again, when a…
Cabinetwork · Furniture
