us, with the radii D r, D s, &c., describe theconcentric circles, s q, &c., representing the coveringboards in plan. Tlirough the centre D draw PI K per-pendicular to G C, indefiniteh- extending it through K.Join the points of division of the semi-circle, A b, b m,m t, by straight lines,… … To find the covering of an ogee dome, hexagonal inplan. Let A B C D E F (No. 1, Fig. 93) be the plan of thedome, and H KL (No. 2) the elevation, on the di-ameter F C. Divide H K into any number of equalparts in 1, 2, 3, 4, 5, k, and through these draw per-pendiculars to H L, and produce them to…
