Modern carpentry and joinery : being a compilation of the very best things and most modern and practical methods known in the arts of carpentry and joinery (1910)
Hodgson, Frederick Thomas, 1836- · Chicago : F. J. Drake & Co. · leaf 167
in the eleva-tion, is seen at a D in No. 1; the bevel of the end h i isseen at A a in No. 3, and that of the end e f at b c. To draw the ribs of a regular octagonal niche.^ Fig. 28.—Let No. 1 be the plan, and No. 2 the eleva-tion of the niche. It is obvious that the curve of thecentre rib H G will…
Carpentry
