ce, &c.; the other half gives the planand sections of the lower parts, the dotted lines show-ing the Mandow back. Fig. 57 is a vertical section and Fig. 58 an enlargedsection through the boxings. The framed pilaster cov-ering the boxing is cut at the level of the windowboard, and hung to the… … tion in Fig. 55. The windowback is carried behind theelbows, and grooved to receivethe latter. The rails of thesoffit must be wide enough tocover the boxings, and shouldhave the boxing back tongued
