the horizontal and the line c e thevertical projections. 2nd. If the cone is cut parallel tobase, as in g h, the section will be a circle, of v/hichg h will be the diameter. 3rd. When the section planeis oblique to the axis, and passes through the oppo-site sides of the cone, as m p h, the section… … Fig. 43. tion is a parabola r s h t u. 5th. When the sectionplane is such as to pass through the sides of anothercone formed by producing the sides of the first be- SOLID GEOMETRY 73 yond the vertex, as the plane q h, the resulting curvein each cone in a hyperbola. Several methods of drawing the…
