running. It will be seenthat after passing the locking notch, D, Fig. 94, will in itsturn raise the hook C, which will ride on the edge of D,and hold A clear of the count wheel until the locking notchof D is again reached, when a deep notch in the wheel willallow C to catch, as in Fig. 93, unless C… … Fig. 93. Upper Portion of Striking Train Locked. THE MODERN CLOCK. 303
