ngecoupling insulated in this way, the heavily shaded parts rep-resenting the insulating material. The larger machines, which on account of their weightcannot be insulated, must be permanently and effectuallygrounded. Where the engine and dynamo are direct con-nected a very good ground is obtained… … Figure 23 water pipes. In the case of high tension machines, especiallyseries arc, the machine should always be surrounded by aninsulated platform so arranged that a man must stand on it inorder to touch any part of the machine either live parts or 50 MODERN ELECTRICAL CONSTRUCTION. frame and in…
