The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 213
induc-tion coil is attached to spark plug E which is placed inthe combustion chamber of the cylinder. One terminalof the induction coil M is grounded on the engine, as 210 The Modern Gas Tractor at Q. The central terminal of the switch F goes tothe insulated terminal of the timer D. One of the… … Fig. 75.—Two Cylinder Battery and Coil Ignition System. leads going to one side of the switch while the othergoes to the primary terminals of the coil M. Eithermagneto or battery may be used, depending UDon theposition of the switch lever. When the switch is thrownin contact the circuit is still…
Farm engines · Internal combustion engines
