The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 324
Fig. 136a.—^The Cuddy Automatic Steering Device Appliedto Ackerman Type Front Axle. readily ascertained. In the device shown at Fig. 136-Athe action is somewhat similar to that previously de-scribed, except that two wheels are used and a systemof leverage is employed to change the direction of The… … Fig. 137.—Showing Important Members of Conventional PowerTransmission System. 318 The Modern Gas Tractor movement of the main steering member on the frontaxle. Methods of Final Drive.—(3ne of the importantproblems that the tractor designer is called upon tosolve is that of power transmission from…
Farm engines · Internal combustion engines
