f known tension, so as to confine the strokeof the indicator piston within a certain small limit. Second. The stroke of the indicator piston is com-municated by a multiplying mechanism of levers andparallel motion to a pencil moving in a straight line;the distance through which the pencil moves… … Sectional View Crosby Indicator engine throughout an entire revolution is communi-cated to a small drum attached to and forming a partof the indicator. The movement of the drum isrotative and in a direction at right angles to the move-ment of the pencil. The forward stroke of the engine 204…
