with a movable combiningtube, operated by a lever which allows them to beadjusted to work correctly at different pressures ofsteam, and under the many conditions which injectorsare required to work. Table 20—Size and Capacity 05 Copper Pipe Iron Pipe Outside Inside Gallons of N.24 Water OQ^ Steam… … INJECTORS, STEAM GAUGES, ETC. 371 To Operate. Have the combining tube in position toallow a sufficient quantity of water to condense thesteam when the starting valve is full open, then openthe starting valve slightly; when water shows at over-flow, open full. Regulate the water by moving…
