Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 663
194 and how the graduating valve EV 110is controlled by the piston JLV 193. This view also showsthe different positions of the brake valve handle. Fig.268 is a top view of the valve with the cover, slide valve 634 LOCOMOTIVE ENGINEERING and handle removed, showing seat and connections forthe… … EV60 visa JCOPPER «PC TO SUPfLCMCNt/UIV Fig. 267 The main reservoir pipe is connected from the pressurecontroller to chamber B (Fig. 26/) in the top of thevalve. The brake pipe is connected to chamber A. Dis-charge of brake pipe air to the atmosphere for serviceapplications occurs through ports F…
Locomotives
